bdcom P3310D как организовать канал ?

Reply to this topic

dexusden11

dexusden11
Posted

Доброго всем времени! Как организовать канал между двумя компьютерами? Первый подключен к порту g0/5 , второй к ONU epon0/3:1 . На данный момент есть только дефолтовый vlan1

Share this post

Link to post
Share on other sites

Nikita Devyatyarov

Nikita Devyatyarov
Posted

Добрый день. Можете подсказать на каком этапе появляются сложности? Если нужны access порты, то на g0/5:

 switchport mode access
 switchport pvid 100



На ОНУ:

epon onu port 1 ctc vlan mode tag 100 priority 0



Ну и создать vlan на olt



vlan 100

Share this post

Link to post
Share on other sites

dexusden11

dexusden11
Posted (edited)

Настройки ONU epon0/3:1 после команды "epon onu port 1 ctc vlan mode tag 100 priority 0"остаются без изменений (режим Transparent). Не работает канал. Два компьютера между собой не пингуются.



Switch_config#show configuration
!version 10.1.0F build 121083
service timestamps log date
service timestamps debug date
logging buffered 4096
!
port-protected 1

!
ip default-gateway 192.168.20.254
!
!
spanning-tree mode rstp

!
aaa authentication login default local
aaa authentication enable default none
aaa authorization exec default local
!
username admin password 0 admin
!

epon oam-version 1 0x30
epon oam-version 2 0x21
epon oam-version 3 0x20
!
!!slot 0 89 unknow CARD
interface GigaEthernet0/1
 description UpLink
 switchport trunk vlan-untagged 1
 switchport mode dot1q-tunnel-uplink
!
interface GigaEthernet0/2
 switchport trunk vlan-untagged 1
 switchport mode dot1q-tunnel-uplink
!
interface GigaEthernet0/3
 switchport trunk vlan-untagged 1
 switchport mode dot1q-tunnel-uplink
!
interface GigaEthernet0/4
 switchport trunk vlan-untagged 1
 switchport mode dot1q-tunnel-uplink
!
interface GigaEthernet0/5
 switchport trunk vlan-allowed 100
 switchport trunk vlan-untagged none
 switchport mode access
 switchport pvid 100
!
interface GigaEthernet0/6
 switchport trunk vlan-untagged 1
 switchport mode dot1q-tunnel-uplink
!
interface EPON0/1
 epon bind-onu mac f8f0.8211.f243 2
 switchport protected 1
!
interface EPON0/2
 description gpon
 epon bind-onu mac f8f0.8211.f23b 1
 epon bind-onu mac f8f0.8211.f229 2
 epon bind-onu mac f8f0.8211.f253 3
 epon bind-onu mac f8f0.8262.afee 4
 epon bind-onu mac f8f0.8211.f24b 5
 epon bind-onu mac f8f0.8211.f22d 6
 epon bind-onu mac f8f0.8211.f223 7
 filter bpdu
 filter dhcp
 switchport trunk vlan-untagged 1
 switchport rate-limit 16000 ingress
 switchport rate-limit 16000 egress
 switchport protected 1
!
interface EPON0/3
 epon bind-onu mac f8f0.8262.afe6 1
 switchport trunk vlan-untagged none
 switchport protected 1
!
interface EPON0/4
 switchport protected 1
!
!!slot end
!
interface VLAN1
 ip address 192.168.20.253 255.255.255.0
!
!
!
vlan 1,100
!

ip http server
!

time-zone tz 3 0
!
!Pending configurations for absent linecards:
!
!No configurations pending global

Edited by dexusden11
