ASR1001x не поднимается 10G интерфейс.

Дароф!

Имеется железка:


Cisco IOS XE Software, Version 16.06.02
Cisco IOS Software [Everest], ASR1000 Software (X86_64_LINUX_IOSD-UNIVERSALK9-M), Version 16.6.2, RELEASE SOFTWARE (fc2)

sh platform
Chassis type: ASR1001-X

Slot      Type                State                 Insert time (ago)
--------- ------------------- --------------------- -----------------
0         ASR1001-X           ok                    23:36:31
 0/0      BUILT-IN-2T+6X1GE   ok                    23:35:16
R0        ASR1001-X           ok, active            23:36:31
F0        ASR1001-X           ok, active            23:36:31
P0        ASR1001-X-PWR-AC    ok                    23:36:07
P1        ASR1001-X-PWR-AC    ok                    23:36:06
P2        ASR1001-X-FANTRAY   ok                    23:36:08

Slot      CPLD Version        Firmware Version
--------- ------------------- ---------------------------------------
0         14041015            16.3(2r)
R0        14041015            16.3(2r)
F0        14041015            16.3(2r)

Не удается поднять 10G линк



В логах следующие сообщение:


Mar  6 11:21:39 UTC: %IOSXE_RP_ALARM-6-INFO: ASSERT CRITICAL xcvr container 0/0/0 Transceiver Missing - Link Down
Mar  6 11:21:39 UTC: %ALARM-3-CLEAR: CLEAR CRITICAL TenGigabitEthernet0/0/0 Physical Port Link Down entity deleted
Mar  6 11:21:39 UTC: %TRANSCEIVER-6-REMOVED: SIP0/0: Transceiver module removed from TenGigabitEthernet0/0/0
Mar  6 11:21:56 UTC: %TRANSCEIVER-6-INSERTED: SIP0/0: transceiver module inserted in TenGigabitEthernet0/0/0
Mar  6 11:21:58 UTC: %IOSXE_RP_ALARM-6-INFO: CLEAR CRITICAL xcvr container 0/0/0 Transceiver Missing - Link Down
Mar  6 11:21:58 UTC: %IOSXE_RP_ALARM-6-INFO: ASSERT CRITICAL TenGigabitEthernet0/0/0 Physical Port Link Down
Mar  6 11:21:58 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to local fault
Mar  6 11:21:58 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to local fault
Mar  6 11:21:58 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to local fault
Mar  6 11:21:59 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to local fault
Mar  6 11:22:03 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to local fault
Mar  6 11:22:03 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to local fault
Mar  6 11:22:05 UTC: %IOSXE_SPA-6-UPDOWN: Interface TenGigabitEthernet0/0/0, link down due to remote fault



При этом, модуль определяется, даже можно снять какие-то показания.



sh hw-module subslot 0/0 transceiver 0 idprom detail


IDPROM for transceiver TenGigabitEthernet0/0/0:
  Description                               = SFP+ optics (type 130)
  Transceiver Type:                         = SFP+ 10GBASE-ER (276)
  Product Identifier (PID)                  = SFP-10G-ER
  Vendor Revision                           = A
  Serial Number (SN)                        = EA110928016
  Vendor Name                               = OEM
  Vendor OUI (IEEE company ID)              = 00.90.65 (36965)
  CLEI code                                 = COUIAM3CAA
  Cisco part number                         = 10-2415-01
  Device State                              = Enabled.
  Date code (yy/mm/dd)                      = 11/10/26
  Connector type                            = LC.
  Encoding                                  = 8B10B
  Nominal bitrate                           = 10GE (10300 Mbits/s)
  Minimum bit rate as % of nominal bit rate = 103 % of 10300 Mbits/s
  Maximum bit rate as % of nominal bit rate = 99 % of 10300 Mbits/s
  The transceiver type is 276
  Link reach for 9u fiber (km)              = ER(40km) (40)
                                              8GFC-ER(40km) (40)
                                              8GFC-CWDM(40km) (40)
  Link reach for 9u fiber (m)               = ER(40km) (255)
                                              ZR(80km) (255)
                                              DWDM(80km) (255)
                                              8GFC-ER(40km) (255)
                                              8GFC-CWDM(40km) (255)
  Nominal laser wavelength                  = 1558 nm.
  DWDM wavelength fraction                  = 1558.0  nm.
  Supported options                         = Tx disable
                                              Tx fault signal
                                              Loss of signal (standard implementation)
  Supported enhanced options                = Alarms for monitored parameters
                                              Software Tx fault monitoring
                                              Software Rx LOS monitoring
  Diagnostic monitoring                     = Digital diagnostics supported
                                              Diagnostics are internally calibrated
                                              Rx power measured is "Average power"
  Transceiver temperature operating range   = not specified
  Minimum operating temperature             = 0 C
  Maximum operating temperature             = 70 C
  High temperature alarm threshold          = +85.000 C
  High temperature warning threshold        = +80.000 C
  Low temperature warning threshold         =  -5.000 C
  Low temperature alarm threshold           =  -10.000 C
  High voltage alarm threshold              = 3700.0 mVolts
  High voltage warning threshold            = 3599.9 mVolts
  Low voltage warning threshold             = 3000.0 mVolts
  Low voltage alarm threshold               = 2900.0 mVolts
  High laser bias current alarm threshold   = 85.000 mAmps
  High laser bias current warning threshold = 80.000 mAmps
  Low laser bias current warning threshold  = 12.000 mAmps
  Low laser bias current alarm threshold    = 10.000 mAmps
  High transmit power alarm threshold       =  6.0 dBm
  High transmit power warning threshold     =  5.0 dBm
  Low transmit power warning threshold      = -2.0 dBm
  Low transmit power alarm threshold        = -3.0 dBm
  High receive power alarm threshold        =  0.0 dBm
  High receive power warning threshold      = -1.0 dBm
  Low receive power warning threshold       = -16.0 dBm
  Low receive power alarm threshold         = -17.0 dBm
  External Calibration: bias current slope  = 1.000
  External Calibration: bias current offset = 0



Может кто сталкивался по подобным поведением?





Share this post


Link to post
Share on other sites

@darkagent



sh hw-module subslot 0/0 transceiver 0 status
The Transceiver in slot 0 subslot 0 port 0 is enabled.
  Module temperature                        = +36.406 C
  Transceiver Tx supply voltage             = 3202.5 mVolts
  Transceiver Tx bias current               = 45448 uAmps
  Transceiver Tx power                      =  1.5 dBm
  Transceiver Rx optical power              = -10.1 dBm



Share this post


Link to post
Share on other sites

@darkagent

show interfaces diagnostics optics xe-3/0/0
Physical interface: xe-3/0/0
    Laser bias current                        :  5.342 mA
    Laser output power                        :  0.6150 mW / -2.11 dBm
    Module temperature                        :  42 degrees C / 108 degrees F
    Laser rx power                            :  0.4660 mW / -3.32 dBm
    Laser bias current high alarm             :  Off
    Laser bias current low alarm              :  Off
    Laser bias current high warning           :  Off
    Laser bias current low warning            :  Off
    Laser output power high alarm             :  Off
    Laser output power low alarm              :  Off
    Laser output power high warning           :  Off
    Laser output power low warning            :  Off
    Module temperature high alarm             :  Off
    Module temperature low alarm              :  Off
    Module temperature high warning           :  Off
    Module temperature low warning            :  Off
    Laser rx power high alarm                 :  Off
    Laser rx power low alarm                  :  Off
    Laser rx power high warning               :  Off
    Laser rx power low warning                :  Off
    Module not ready alarm                    :  On
    Module power down alarm                   :  Off
    Tx data not ready alarm                   :  Off
    Tx not ready alarm                        :  Off
    Tx laser fault alarm                      :  Off
    Tx CDR loss of lock alarm                 :  Off
    Rx not ready alarm                        :  On
    Rx loss of signal alarm                   :  Off
    Rx CDR loss of lock alarm                 :  On
    Laser bias current high alarm threshold   :  16.000 mA
    Laser bias current low alarm threshold    :  2.000 mA
    Laser bias current high warning threshold :  15.000 mA
    Laser bias current low warning threshold  :  2.500 mA
    Laser output power high alarm threshold   :  1.0000 mW / 0.00 dBm
    Laser output power low alarm threshold    :  0.1770 mW / -7.52 dBm
    Laser output power high warning threshold :  0.7940 mW / -1.00 dBm
    Laser output power low warning threshold  :  0.1990 mW / -7.01 dBm
    Module temperature high alarm threshold   :  88 degrees C / 190 degrees F
    Module temperature low alarm threshold    :  -41 degrees C / -42 degrees F
    Module temperature high warning threshold :  85 degrees C / 185 degrees F
    Module temperature low warning threshold  :  -40 degrees C / -40 degrees F
    Laser rx power high alarm threshold       :  1.7783 mW / 2.50 dBm
    Laser rx power low alarm threshold        :  0.0316 mW / -15.00 dBm
    Laser rx power high warning threshold     :  1.5849 mW / 2.00 dBm
    Laser rx power low warning threshold      :  0.0398 mW / -14.00 dBm



Но нужно учесть, что в разрыв между jun и asr стоит dwdm, при этом, на dwdm линки активный.

Share this post


Link to post
Share on other sites

Внутри транспондера DWDM каша похоже. Физика есть а вот логика не сходится.

Share this post


Link to post
Share on other sites

@Garra-67 А что там может быть такого? Принял на одном порту передал на другой.

что интересно, если на asr линк потушить (int sh), то транспондере это видно.

Edited by unfraget

Share this post


Link to post
Share on other sites

С ASR модуль светит аж 1.5, это сильно много, возможно приемник на dwdm в клипе. Попробуйте поставить аттенюатор.

Или сами модули dwdm?

Edited by Garra-67

Share this post


Link to post
Share on other sites
В 06.03.2018 в 15:49, Garra-67 сказал:

С ASR модуль светит аж 1.5, это сильно много, возможно приемник на dwdm в клипе. Попробуйте поставить аттенюатор.

Или сами модули dwdm?



Здравия!

ну оказалось всё гораздо печальнее, переткнул линк из ASR в  Juniper Ex4500 и линк поднялся, похоже, что проблема всё таки в IOS

Share this post


Link to post
Share on other sites

коллега тут недавно вообще никак не смог уговорить залинковаться по 10г циску 4900м и длинк 3620



Share this post


Link to post
Share on other sites

Всем привет!

Как и предполагалось проблема в IOS.
Откатившись до asr1001x-universalk9.03.16.06.S.155-3.S6-ext.SPA.bin линк поднялся.



На

asr1001x-universalk9.16.03.05.SPA.bin

asr1001x-universalk9.16.06.02.SPA.bin

Не работает.



Share this post


Link to post
Share on other sites
